Product Name:Textile Printer FY-2308TX

Product Details:
Model:
FY-2308TX
Select Payment and Shipping Terms:
Min. Order Quantity:
0
Place of Origin:
Min. Order:
FOB Price:
0.00-0.00 /
Shipping Terms:
Shippment Port:
Payment Terms:
Show Buyers your Ability to Supply:
Production Capacity:
0
Delivery Time:
Packaging:

Detailed Product Description:

CHALLENGER Textile Printer FY-2308TX:
Equipped with industrial piezo printhead with 254 nozzles, printing width of 36mm, and 720 DPI printing resolution.
1 4 level grey scale printhead;
2
The third generation smart pressure sensitive control system, which monitors ink usage inside the printhead and supplies ink on demand;
3
Double channel ink supply system with smart channel-change system;
4
Color-active system can be connected with or off the printer, to meet different  requirements to customers.

Model

FY-2308TX

Printhead

Drop on demand Piezo Head

Number of Printhead

8 Heads

Maximum Print Width

2300mm

Print Speed

Draft

55 M2/hr

Standard

41 M2/hr

High Quality

28 M2/hr

Media

Max.Weight

40kg

Type

Polyester.

Height

4mm(Max)

Ink

Type

Specified disperse ink

Capacity

2 liter bottle package

Auto Cleaning System

Software auto-control cleaning and moisturizing

Print Interface

USB 2.0

Power Specification

Printer: AC 220V 1000W
Colour active machine: AC 380V 4100W
Air filter unit: AC380V 1100W

Operation Environment

Temperature 20℃-28℃Humidity 40%-60%

Compatible RIP Software

 WASATCH

Dimension&Weight

Machine

Printer :L3758mm X W813mm X H1350mm
Colour active machine: L3190mm X W620mm X H750mm
Air filter unit: L680mm X W680mm X H16850mm
